No.
|
Dimension
|
Fixing holes
|
Gear teeth
|
Tooth force
|
Basic load ratings
|
Weight
|
|
Static
|
Dynamic
|
|
Da
|
Di
|
di
|
da
|
La
|
Li
|
na
|
ni
|
do
|
m
|
z
|
Fz norm
|
Fz max
|
Cor
|
Coa
|
Cr
|
Ca
|
|
mm
|
mm
|
mm
|
mm
|
mm
|
mm
|
-
|
-
|
mm
|
mm
|
-
|
kN
|
kN
|
kN
|
kN
|
kN
|
kN
|
kg
|
|
134.50.3150 G3
|
3415
|
3090
|
2736
|
3104
|
3325
|
2950
|
48
|
48
|
2760
|
24
|
115
|
440
|
820
|
4110
|
28285
|
1820
|
7450
|
5128
|
|
134.50.3550 G3
|
3815
|
3490
|
3120
|
3504
|
3725
|
3350
|
54
|
54
|
3144
|
24
|
131
|
440
|
820
|
4618
|
31872
|
1935
|
7919
|
5916
|
|
134.50.4000 G3
|
4265
|
3940
|
3576
|
3954
|
4175
|
3800
|
60
|
60
|
3600
|
24
|
150
|
440
|
820
|
5190
|
35908
|
2059
|
8433
|
6623
|
|
134.50.4500 G3
|
4765
|
4440
|
4080
|
4454
|
4675
|
4300
|
68
|
68
|
4104
|
24
|
171
|
440
|
820
|
5825
|
40393
|
2189
|
9051
|
7427
|
|
134.50.4750 G3
|
5015
|
4690
|
4320
|
4704
|
4925
|
4550
|
76
|
76
|
4344
|
24
|
181
|
440
|
820
|
6143
|
42635
|
2250
|
9297
|
7840
|
|
