No.
|
Dimension
|
Fixing holes
|
Gear teeth
|
Tooth force
|
Basic load ratings
|
Weight
|
|
Static
|
Dynamic
|
|
Da
|
Di
|
di
|
da
|
La
|
Li
|
na
|
ni
|
do
|
m
|
z
|
Fz norm
|
Fz max
|
Cor
|
Coa
|
Cr
|
Ca
|
|
mm
|
mm
|
mm
|
mm
|
mm
|
mm
|
-
|
-
|
mm
|
mm
|
-
|
kN
|
kN
|
kN
|
kN
|
kN
|
kN
|
kg
|
|
132.50.3150 G3
|
3571.2
|
3196
|
2885
|
3210
|
3350
|
2975
|
48
|
48
|
3504
|
24
|
146
|
420
|
760
|
3894
|
28222
|
1770
|
7443
|
5298
|
|
132.50.3550 G3
|
3955.2
|
3596
|
3285
|
3610
|
3750
|
3375
|
54
|
54
|
3888
|
24
|
162
|
420
|
760
|
4402
|
31810
|
1887
|
7913
|
5830
|
|
132.50.4000 G3
|
4411.2
|
4046
|
3735
|
4060
|
4200
|
3825
|
60
|
60
|
4344
|
24
|
181
|
420
|
760
|
4974
|
35846
|
2011
|
8427
|
6578
|
|
132.50.4500 G3
|
4915.2
|
4546
|
4235
|
4560
|
4700
|
4325
|
68
|
68
|
4848
|
24
|
202
|
420
|
760
|
5609
|
40330
|
2144
|
9036
|
7456
|
|
132.50.4750 G3
|
5179.2
|
4796
|
4485
|
4810
|
4950
|
4575
|
76
|
76
|
5112
|
24
|
213
|
420
|
760
|
5927
|
42573
|
2209
|
9292
|
7870
|
|
