No.
|
Dimension
|
Fixing holes
|
Gear teeth
|
Tooth force
|
Basic load ratings
|
Weight
|
|
Static
|
Dynamic
|
|
Da
|
Di
|
di
|
da
|
La
|
Li
|
na
|
ni
|
do
|
m
|
z
|
Fz norm
|
Fz max
|
Cor
|
Coa
|
Cr
|
Ca
|
|
mm
|
mm
|
mm
|
mm
|
mm
|
mm
|
-
|
-
|
mm
|
mm
|
-
|
kN
|
kN
|
kN
|
kN
|
kN
|
kN
|
kg
|
|
132.32.2240 G3
|
2552.4
|
2270
|
2022
|
2281
|
2395
|
2100
|
40
|
40
|
2502
|
18
|
139
|
228
|
401
|
1862
|
15459
|
1028
|
3280
|
1975
|
|
132.32.2500 G3
|
2822.4
|
2530
|
2282
|
2541
|
2655
|
2360
|
44
|
44
|
2772
|
18
|
154
|
228
|
401
|
2085
|
17255
|
1091
|
3459
|
2260
|
|
132.32.2800 G3
|
3136
|
2830
|
2582
|
2841
|
2955
|
2660
|
48
|
48
|
3080
|
20
|
154
|
260
|
465
|
2341
|
19329
|
1158
|
3700
|
2576
|
|
132.32.3150 G3
|
3476
|
3180
|
2932
|
3191
|
3305
|
3010
|
56
|
56
|
2420
|
20
|
171
|
260
|
465
|
2640
|
21748
|
1235
|
3940
|
2828
|
|
132.32.3550 G3
|
3889.6
|
3580
|
3332
|
3591
|
3705
|
3410
|
66
|
66
|
2828
|
22
|
174
|
295
|
525
|
2982
|
24513
|
1316
|
4204
|
3249
|
|
132.32.4000 G3
|
4351.6
|
4030
|
3782
|
4041
|
4155
|
3860
|
72
|
72
|
4290
|
22
|
195
|
295
|
525
|
3367
|
27623
|
1405
|
4481
|
3752
|
|
