No.
|
Dimension
|
Fixing holes
|
Gear teeth
|
Tooth force
|
Basic load ratings
|
Weight
|
|
Static
|
Dynamic
|
|
Da
|
Di
|
di
|
da
|
La
|
Li
|
na
|
ni
|
do
|
m
|
z
|
Fz norm
|
Fz max
|
Cor
|
Coa
|
Cr
|
Ca
|
|
mm
|
mm
|
mm
|
mm
|
mm
|
mm
|
-
|
-
|
mm
|
mm
|
-
|
kN
|
kN
|
kN
|
kN
|
kN
|
kN
|
kg
|
|
132.25.1800 G3
|
2076.8
|
1826
|
1619
|
1836
|
1925
|
1685
|
36
|
36
|
2032
|
16
|
127
|
172
|
303
|
1348
|
10308
|
728
|
2108
|
1126
|
|
132.25.2000 G3
|
2298.8
|
2026
|
1819
|
2036
|
2125
|
1885
|
44
|
44
|
2224
|
16
|
139
|
172
|
306
|
1502
|
11454
|
772
|
2230
|
1216
|
|
132.25.2240 G3
|
2516.4
|
2266
|
2059
|
2276
|
2366
|
2125
|
48
|
48
|
2466
|
18
|
137
|
202
|
358
|
1687
|
12830
|
821
|
2367
|
1378
|
|
132.25.2500 G3
|
2786.4
|
2526
|
2319
|
2536
|
2625
|
2385
|
54
|
54
|
2736
|
18
|
152
|
202
|
358
|
1887
|
14321
|
870
|
2509
|
1567
|
|
132.25.2800 G3
|
3096
|
2826
|
2619
|
2836
|
2925
|
2685
|
60
|
60
|
3040
|
20
|
152
|
232
|
407
|
2118
|
16041
|
926
|
2665
|
1785
|
|
|
|
| |
|
Equivalences
|
|
31-25 1800/2-06800
|
191.25.1800.990.41.1502
|
|
31-25 2000/2-06810
|
191.25.2000.990.41.1502
|
|
31-25 2240/2-06820
|
191.25.2240.990.41.1502
|
|
31-25 2500/2-06830
|
191.25.2500.990.41.1502
|
|
31-25 2800/2-06840
|
191.25.2800.990.41.1502
|
|
|
|
|
|
|
|
|
