No.
|
Dimension
|
Fixing holes
|
Gear teeth
|
Tooth force
|
Basic load ratings
|
Weight
|
|
Static
|
Dynamic
|
|
Da
|
Di
|
di
|
da
|
La
|
Li
|
na
|
ni
|
do
|
m
|
z
|
Fz norm
|
Fz max
|
Cor
|
Coa
|
Cr
|
Ca
|
|
mm
|
mm
|
mm
|
mm
|
mm
|
mm
|
-
|
-
|
mm
|
mm
|
-
|
kN
|
kN
|
kN
|
kN
|
kN
|
kN
|
kg
|
|
014.20.0314 G1
|
386
|
315.5
|
225
|
312.5
|
360
|
275
|
20
|
24
|
235
|
5
|
47
|
11.9
|
22.7
|
192
|
448
|
140
|
140
|
22
|
|
014.20.0414 G1
|
486
|
415.5
|
325
|
412.5
|
460
|
375
|
24
|
24
|
335
|
5
|
67
|
177
|
262
|
2480
|
5600
|
1110
|
1690
|
31
|
|
014.20.0544 G1
|
616
|
545.5
|
444
|
542.5
|
590
|
505
|
32
|
32
|
456
|
6
|
76
|
237
|
350
|
3250
|
7400
|
1230
|
1880
|
42
|
|
014.20.0644 G1
|
716
|
645.5
|
546
|
642.5
|
690
|
605
|
36
|
36
|
558
|
6
|
93
|
237
|
350
|
3850
|
8800
|
1310
|
2000
|
50
|
|
014.20.0744 G1
|
816
|
745.5
|
648
|
742.5
|
790
|
705
|
40
|
40
|
660
|
6
|
110
|
237
|
350
|
4450
|
10100
|
1380
|
2110
|
58
|
|
014.20.0844 G1
|
916
|
845.5
|
736
|
842.5
|
890
|
805
|
40
|
40
|
752
|
8
|
94
|
314
|
467
|
5100
|
11500
|
1450
|
2220
|
69
|
|
014.20.0944 G1
|
1016
|
945.5
|
840
|
942.5
|
990
|
905
|
44
|
44
|
856
|
8
|
107
|
314
|
467
|
5700
|
12800
|
1510
|
2310
|
76
|
|
014.20.1094 G1
|
1166
|
1095.5
|
984
|
1092.5
|
1140
|
1055
|
48
|
48
|
1000
|
8
|
125
|
314
|
467
|
6600
|
14900
|
2440
|
1600
|
91
|
|
