Dia.0455mm-1455mm-VSU series
|
No. |
Dimension |
Fixing holes |
Gear teeth |
Tooth force |
Basic load ratings |
Weight |
||||||||||||
|
Static |
Dynamic |
|||||||||||||||||
|
Da |
Di |
di |
da |
La |
Li |
na |
ni |
do |
m |
z |
Fz norm |
Fz max |
Cor |
Coa |
Cr |
Ca |
||
|
mm |
mm |
mm |
mm |
mm |
mm |
- |
- |
mm |
mm |
- |
kN |
kN |
kN |
kN |
kN |
kN |
kg |
|
|
010.25.0455 |
555 |
457 |
355 |
453 |
515 |
395 |
18 |
18 |
/ |
/ |
/ |
/ |
/ |
453 |
1213 |
249 |
289 |
53 |
|
010.25.0555 |
655 |
557 |
455 |
553 |
615 |
495 |
20 |
20 |
/ |
/ |
/ |
/ |
/ |
553 |
1480 |
268 |
311 |
65 |
|
010.25.0655 |
755 |
657 |
555 |
653 |
715 |
595 |
24 |
24 |
/ |
/ |
/ |
/ |
/ |
653 |
1746 |
284 |
331 |
76 |
|
010.25.0755 |
855 |
753 |
655 |
757 |
815 |
695 |
24 |
24 |
/ |
/ |
/ |
/ |
/ |
752 |
2013 |
300 |
349 |
90 |
|
010.25.0855 |
955 |
853 |
755 |
857 |
915 |
795 |
28 |
28 |
/ |
/ |
/ |
/ |
/ |
852 |
2280 |
316 |
367 |
101 |
|
010.25.0955 |
1055 |
953 |
855 |
957 |
1015 |
895 |
30 |
30 |
/ |
/ |
/ |
/ |
/ |
952 |
2546 |
328 |
382 |
115 |
|
010.25.1055 |
1155 |
1053 |
955 |
1057 |
1115 |
995 |
30 |
30 |
/ |
/ |
/ |
/ |
/ |
1051 |
2813 |
340 |
396 |
128 |
|
010.25.1155 |
1255 |
1157 |
1055 |
1153 |
1215 |
1095 |
36 |
36 |
/ |
/ |
/ |
/ |
/ |
1151 |
3080 |
351 |
409 |
139 |
|
010.25.1255 |
1355 |
1257 |
1155 |
1253 |
1315 |
1195 |
42 |
42 |
/ |
/ |
/ |
/ |
/ |
1240 |
3346 |
364 |
424 |
150 |
|
010.25.1355 |
1455 |
1357 |
1255 |
1353 |
1415 |
1295 |
42 |
42 |
/ |
/ |
/ |
/ |
/ |
1350 |
3613 |
374 |
435 |
163 |
|
010.25.1455 |
1555 |
1457 |
1355 |
1453 |
1515 |
1395 |
48 |
48 |
/ |
/ |
/ |
/ |
/ |
1450 |
3879 |
383 |
447 |
174 |
|
Equivalences
|
||
|
/
|
10-25 0455/0-04010
|
/
|
|
/
|
10-25 0555/0-04020
|
/
|
|
/
|
10-25 0655/0-04030
|
/
|
|
VSU250755
|
10-25 0755/0-04040
|
/
|
|
VSU250855
|
10-25 0855/0-03010
|
060.25.0855.500.11.1503
|
|
VSU250955
|
10-25 0955/0-03020
|
060.25.0955.500.11.1503
|
|
VSU251055
|
10-25 1055/0-03030
|
060.25.1055.500.11.1503
|
|
/
|
10-25 1155/0-03040
|
060.25.1155.500.11.1503
|
|
/
|
10-25 1255/0-03050
|
060.25.1255.500.11.1503
|
|
/
|
10-25 1355/0-03060
|
060.25.1355.500.11.1503
|
|
/
|
10-25 1455/0-03070
|
060.25.1455.500.11.1503
|
