No.
|
Dimension
|
Fixing holes
|
Gear teeth
|
Tooth force
|
Basic load ratings
|
Weight
|
|
Static
|
Dynamic
|
|
Da
|
Di
|
di
|
da
|
La
|
Li
|
na
|
ni
|
do
|
m
|
z
|
Fz norm
|
Fz max
|
Cor
|
Coa
|
Cr
|
Ca
|
|
mm
|
mm
|
mm
|
mm
|
mm
|
mm
|
-
|
-
|
mm
|
mm
|
-
|
kN
|
kN
|
kN
|
kN
|
kN
|
kN
|
kg
|
|
I.20.0314 G1
|
418
|
315.5
|
225
|
312.5
|
390
|
275
|
8
|
12
|
235
|
5
|
47
|
11.9
|
22.7
|
89
|
208
|
140
|
140
|
21
|
|
I.20.0414 G1
|
518
|
415.5
|
325
|
412.5
|
490
|
375
|
8
|
12
|
335
|
5
|
67
|
17.7
|
26.2
|
110
|
295
|
111
|
169
|
27.5
|
|
I.20.0544 G1
|
648
|
545.5
|
444
|
542.5
|
620
|
505
|
10
|
16
|
456
|
6
|
76
|
23.7
|
35
|
145
|
385
|
123
|
188
|
38.0
|
|
I.20.0644 G1
|
748
|
645.5
|
546
|
642.5
|
720
|
605
|
12
|
18
|
558
|
6
|
93
|
23.7
|
35
|
171
|
455
|
131
|
200
|
45.0
|
|
I.20.0744 G1
|
848
|
745.5
|
648
|
742.5
|
820
|
705
|
12
|
20
|
660
|
6
|
110
|
23.7
|
35
|
198
|
530
|
138
|
211
|
51.5
|
|
I.20.0844 G1
|
948
|
845.5
|
736
|
842.5
|
920
|
805
|
14
|
20
|
752
|
8
|
94
|
31.4
|
46.7
|
224
|
600
|
145
|
222
|
61.5
|
|
I.20.0944 G1
|
1048
|
945.5
|
840
|
942.5
|
1020
|
905
|
16
|
22
|
856
|
8
|
107
|
31.4
|
46.7
|
250
|
670
|
151
|
231
|
67.5
|
|
I.20.1094 G1
|
1198
|
1095.5
|
984
|
1092.5
|
1170
|
1055
|
16
|
24
|
1000
|
8
|
125
|
31.4
|
46.7
|
290
|
770
|
160
|
244
|
81.5
|
|
