No.
|
Dimension
|
Fixing holes
|
Gear teeth
|
Tooth force
|
Basic load ratings
|
Weight
|
|
Static
|
Dynamic
|
|
Da
|
Di
|
di
|
da
|
La
|
Li
|
na
|
ni
|
do
|
m
|
z
|
Fz norm
|
Fz max
|
Cor
|
Coa
|
Cr
|
Ca
|
|
mm
|
mm
|
mm
|
mm
|
mm
|
mm
|
-
|
-
|
mm
|
mm
|
-
|
kN
|
kN
|
kN
|
kN
|
kN
|
kN
|
kg
|
|
E.32.0955 G1
|
1096.2
|
955
|
805
|
955
|
1016
|
845
|
30
|
30
|
1080
|
9
|
120
|
36
|
65
|
1029
|
2754
|
411
|
479
|
165
|
|
E.32.1055 G1
|
1198
|
1055
|
905
|
1055
|
1116
|
945
|
30
|
30
|
1180
|
10
|
118
|
43
|
76
|
1137
|
3043
|
427
|
497
|
183
|
|
E.32.1155 G1
|
1298
|
1155
|
1005
|
1155
|
1216
|
1045
|
36
|
36
|
1280
|
10
|
128
|
43
|
76
|
1245
|
3331
|
442
|
514
|
200
|
|
E.32.1255 G1
|
1398
|
1255
|
1105
|
1255
|
1316
|
1145
|
42
|
42
|
1380
|
10
|
138
|
43
|
76
|
1353
|
3619
|
456
|
531
|
216
|
|
E.32.1355 G1
|
1498
|
1355
|
1205
|
1355
|
1416
|
1245
|
42
|
42
|
1480
|
10
|
148
|
43
|
76
|
1460
|
3908
|
469
|
546
|
234
|
|
E.32.1455 G1
|
1598
|
1455
|
1305
|
1455
|
1516
|
1345
|
48
|
48
|
1580
|
10
|
158
|
43
|
76
|
1568
|
4196
|
482
|
561
|
250
|
|
